供电：三相五线制AC380V±10％，频率50Hz±5％。
信号接口：数字双DMX-512(1990)。
额定功率：12路×4KW. 每个回路最大输出功率可达4kW.40A胶木插输出。
功能特点：
1. 硅箱的核心器件可控硅芯片采用原装进口材料，性能稳定可靠。
2. 良好的散热装置和强制风冷与智能环保控制系统相结合。
3. 高效的抗干扰扼流圈抗干扰能力极强,噪音小,电流上升时间220us-450us。
4. 起始回路设定，预热值设定。
5. 调光曲线可设为线性或开关状态，开关值为50%，开关状态下输入的亮度值大于或等于50%时对应输出回路满输出，否则无输出。
外形尺寸(mm):L515×W485×H14.5
整机重量:15.4KG
Specific References
16 other products in the same category:
Power supply: three-phase five-wire AC380V±10％%, frequency 50Hz±5％%.
Interface: Digital Dual DMX-512(1990).
Rated power: 12 channels× 4kW. The maximum output power of each circuit can reach 4kW.40A Bakelite plug-in output.
Functional features:
1. Silicon controlled silicon chip, the core device of silicon box, is made of imported materials with stable and reliable performance.
2. Good heat dissipation device and forced air cooling combined with intelligent environmental protection control system.
3. High-efficiency anti-interference choke has strong anti-interference ability, low noise and current rising time of 220us-450us.
4. Setting of initial circuit and preheating value.
5. The dimming curve can be set to linear or on-off state, and the on-off value is 50%. When the brightness value of the input in on-off state is greater than or equal to 50%, the corresponding output circuit is fully output, otherwise, there is no output.
Overall dimension (mm):L515×W485×H14.5
Whole machine weight: 15.4KG
