Features: The latest third-generation motherboard, supports RDM, display programming. With built-in program.
Channel mode: 16 international standard DMX512 channels;
Light source: original OSRAM 461W;
Lamp life: 1600H
Voltage: 110-240v.50/60hz
Total power: 700w
Color: 14 colors + white light; with seven-color rainbow effect
Gobo: 17 gobos (including 6 glass gobos)
Prism wheel: a prism wheel (8+16+24+32)
Beam angle: 2.1°
Lens diameter: 189mm
Focusing: using high-precision glass optical lens, electronic linear high-definition adjustment
Atomization: 1 independent atomization effect, soft and natural light spot
Color chip quality: Imported from Italy, special high-temperature resistant raw materials, to achieve strong and bright vividness.
Horizontal/Vertical: The horizontal scanning angle is 540°(16BIT precision scanning), the vertical scanning angle is 270° (16BIT precision scanning)
XY motor: three-phase motor. Three-phase motor drive, powerful, faster, more stable and quieter.
Dimming: 0-100% mechanical dimming, mechanical gating and support
Use optical reset system
Positioning technology: The magnetic positioning system using magnetic devices replaces the traditional Hall positioning system, which has high accuracy, high performance and reliability.
Waterproof protection grade: IP65;
Weight: 31.6KG
Size: Length 428mm*Height 700mm*Width 287mm
