Technical parameter
power application
● Input voltage AC110V-240V, 50-250Hz
● Total power 500W
Bulb Specifications
● The main light source uses a single LED 300W white light with a color temperature of 8000K
● 16 Kerui RGBW 10W full-color LEDs are used around the head
● Lamp bead service life is 20,000 hours
Optical system
● Lighting angle 3°
● Linear dimming 0-100%
● Strobe 0-20s
color wheel
● 1 color disc: 7 color chips + white light
gobo
● 1 rotating gobo wheel: 7 replaceable gobos + 1 white light
● 1 fixed gobo wheel: 8 fixed gobos + 1 white light
Prism effect
● One 16 prism and one honeycomb prism, stackable, variable speed rotation
fog mirror effect
● Independent atomized lens, soft light
focusing
● Electronic focusing: ultra-smoothly adjust the focus, adjust the clarity of the pattern
scan system
● Driven by three-phase motor, fast, quiet, with automatic error correction reset
● Horizontal scan: 540°
● Vertical scan: 270°
cooling system
● Adopt powerful silent fan
● Temperature protection function: when the device temperature reaches 40°, the fan starts to rotate, and when the device reaches 70°, the power is halved
way to control
● International standard DMX512 signal control connection
● Control channel mode 25/18CH
● Product size: 330(L)*230(W)*560(H)mm,
● Product weight: net weight: 15.7kg, gross weight: 20kg
