The main technical parameters
Electrical parameters:
Input voltage: 100V~240V AC, 50/60Hz
Input Power: 450W @ 220V
Power factor: PF>0.9
Light source specifications:
Light source: 350W high brightness LED
Color temperature: 7500K-8000K
Rated life: 50000 hours
color:
1 color wheel: 7 colors + white light
Variable speed bidirectional rainbow effect
Step/Linear conversion color optional
Fixed gobo:
1 fixed gobo wheel: 8 gobos + white light
With variable speed jitter effect, two-way variable speed flow effect
To rotate the gobo wheel:
1 rotating gobo wheel: 7 gobos + white light
The pattern plate adopts a detachable design, which is more convenient to replace the pattern plate
Prism: 1 8 prism, can be rotated in both directions
Focusing: DMX linear focusing, super smooth focus adjustment.
Strobe/dimming: electronic strobe, 0.3-25 times/second / linear dimming
Atomization: independent atomization lens, softer light
Rotation angle:
Driven by three-phase stepping motor, fast, quiet, with automatic return function.
540° horizontally, 270° vertically
Beam angle: DMX linear amplification, beam angle 8-35 degrees free switch
Control mode: international standard DMX512 signal, 3-pin interface + 5-pin interface
18CH 16CH, 2 channel modes for selection
Other functions:
Horizontal and vertical speed adjustable
Adopt powerful silent fan, display LED temperature, reduce power due to overheating, and ensure LED service life
Modular structure for easy maintenance
Housing material/protection level:
High temperature/UV light resistant engineering plastic Protection grade: IP20
weight:
Net weight: 16kg Gross weight: 19kg
Outer packing size: (unit: mm)
390(L)*31(W)*710(H)
Working temperature:
Maximum ambient temperature 45°C
