Input voltage: AC100-240V,50/60Hz

Power limit: 1050W

Life of LED: 20,000 hours

Color temperature: 6500K

Color rendering index: standard mode Ra>75, high-definition mode Ra>90

Luminous flux: 28000LM

Power interface: 16A power plug

Signal interface: three-core canon block

Control mode: DMX512, RDM

Mode: 36 channels of international standard DMX512

Display system: 2.7-inch touch LCD screen, Chinese and English display, 180° rotation.

Color mixing system: independent CMY color mixing system

Color temperature adjustment: independent CTO 2800K-6500K linear adjustment.

Prism wheel: rotate 3 prisms +6 rows of mirrors.

Effect panel: It can simulate dynamic effects such as moving flame and gurgling water.

Color wheel: 6 colors+white light

Fixed gobo: 11 fixed gobo pieces with outer diameter of 25.4mm+ white circle

Rotation gobo: seven plug-in patterns have an outer diameter of 26.9mm, an effective diameter of 16.5mm and a thickness of 1.1mm

Cutting system: 4 independent cutting pieces, each piece can be turned off independently and can rotate 90.

Atomization system: 0~100% linear atomization

Aperture system: 6%~100% smooth adjustment

Zoom system: 6 ~ 50 linear focus

Dimming system: 0-100% linear adjustment

Stroboscopic system: the frequency can reach up to 25Hz, and random stroboscopic and pulse stroboscopic horizontal scanning can be selected: 540° (16 bit precision scanning).

Vertical scanning: 270° (16 bit precision scanning)

Protection level: IP20

Working environment: 0-45℃

Product dimensions: 510L*345W*800H(mm)

Net weight of product:

Gross weight of product:

Product appearance: flame retardant, high temperature resistant, folding integrated lamp hook

Frequency: 50/60Hz

Input voltage: AC220V/50-60Hz

Waterproof grade: IP55

Bulb specification: spherical xenon bulb 5000W

Lamp life: 800-1000 hours

Dielectric strength: 1.5KV

Insulation resistance: >2MΩ

Rotation angle: left and right 110° automatic rotation

The up and down angle can be adjusted manually by 60°

Dimming function: the size of the light column can be adjusted manually

Beam angle: 0.6-0.8°

Cooling method: forced air cooling

Packing size: 740*630*1040(mm)

Packing weight: 65KG

Output color Green

Scan rate: 40Kpps  Angle: 60 degree

Protection level :IP65

Working mode:  Automatic,DMX,ILDA, FB4

Electrical

Input voltage:  AC100~240V/50~60Hz   Rate power: 900W   Fuse: 6A

Light size: L350*W300*H260mm

Net weight:11kg

Flight case Size:L500*W400*H400mm

Gross weight:18kg

Power supply: AC90-240, 50-60HZ

Rated power: <600W

Laser power: RGB20W

Scanning system: 40KPPS high-speed galvanometer scanning system

Laser pattern: The motherboard has 128 built-in laser effect patterns, and the SD card stores hundreds of patterns and animations.

Laser modulation signal: analog modulation or TTL

Laser wavelength: red 638nm, green 525nm, blue 450nm or 465nm

Control mode: ILDA/DMX512/self-propelled/voice control/master-slave/SD

Channel mode: 20CH

Working environment: indoor (10-35) ℃

LCD display operation

Cooling system: fan forced cooling

Output color

True color，Red，Green，Blue，Yellow，Cyan，Magenta，White

Scan rate: 40Kpps  Angle: 60 degree

Protection level :IP65

Working mode Automatic, DMX,ILDA, FB4

Electrical

Input voltage: AC100~240V/50~60Hz   Rate power: 600W   Fuse:3A

Lighting size: L40*W35*H26cm  Net weight :22kg

Flight case size:L 60*W50cm*H46cm Gross weight 30kg

Scan rate: 40Kpps  Angle: 60 degree

Working mode Automatic, DMX, ILDA, FB4

Electrical

Input voltage: AC100~240V/50~60Hz   Rate power: 1100W   Fuse: 6A

Lighting size:  L37*W33.6*H18.5cm  Net weight:21kg

Flight case size:  L50*W46*H40cm     Gross weight:34kg

Model, Laser diode, color, Wavelength/Power

RGB30W ( Red638nm/8W + Green520nm/10W + Blue445nm/12W)

Output color

True color，Red，Green，Blue，Yellow，Cyan，Magenta，White

Scan rate: 40Kpps  Angle: 60 degree

Working mode Automatic, DMX, ILDA, FB4

Electrical

Input voltage: AC100~240V/50~60Hz   Rate power: 700W   Fuse: 6A

Lighting size: L40*W35*H26cm  Net weight :22kg

Flight case size:L 60*W50cm*H46cm Gross weight 30kg

Input voltage: AC100~240V/50~60Hz

Laser Light source: 20W

Color:RGB

Dimmer: 0~100% linear

DMX channels: 27

Working mode: DMX/ILDA/Automatic

Scan Rate: 40Kpps

Basic gobo: 200pcs(SD card gobo 3000pcs, SD card animation 255pcs) Beam parameter: diameter is less than <3mm divergence angle<1.5mrad Laser safety: overload protection

Pan: infinite (include 540,630,900,1800degree) Tilt: infinite (include 270,180,540,1080degree)

Protection level:IP65

Weight:48kg Size: L50*W50*H67CM

Output color

True color，Red，Green，Blue，Yellow，Cyan，Magenta，White

Scan rate: 40Kpps  Angle: 60 degree

Protection level : IP65

Working mode： ILDA, FB4，Automatic, DMX

Electrical

Input voltage: AC100~240V/50~60Hz   Rate power: 1300W   Fuse:10A

Size：51*52*35cm   Net weight:32kg

Flight case size：L57*W57*H55cm     Gross weight：50kg

Input voltage: AC100~240V/50~60Hz

Laser Light source: 30W

Color:RGB

Dimmer: 0~100% linear

DMX channels: 27

Working mode: DMX/ILDA/Automatic

Scan Rate: 40Kpps

Basic gobo: 200pcs(SD card gobo 3000pcs, SD card animation 255pcs) Beam parameter: diameter is less than <3mm divergence angle<1.5mrad Laser safety: overload protection

Pan: infinite (include 540,630,900,1800degree) Tilt: infinite (include 270,180,540,1080degree)

Protection level:IP65

Weight:48kg Size: L50*W50*H67CM

Output color

True color，Red，Green，Blue，Yellow，Cyan，Magenta，White

Scan rate: 40Kpps  Angle: 60 degree

Protection level : IP65

Working mode： ILDA, FB4，Automatic, DMX

Electrical

Input voltage: AC100~240V/50~60Hz   Rate power: 1400W   Fuse:10A

Size：51*52*35cm   Net weight:32kg

Flight case size：L57*W57*H55cm     Gross weight：50kg

Scan rate: 40Kpps  Angle: 60 degree

Working mode Automatic, DMX, ILDA, FB4

Electrical

Input voltage: AC100~240V/50~60Hz   Rate power: 1400W   Fuse: 10A

Size：51*52*35cm   Net weight:34kg

Flight case size：L57*W57*H55cm    Gross weight：54kg
