Technical parameters:

Voltage: AC100~240V 50/60HZ

Power: 500W

Lamp beads: 6070 lamp beads 60W*6, 7070 lamp beads 96, divided into 12 sections.

Control mode: DMX512, self-propelled, master-slave, voice control, with RDM function.

Channel: CH24/CH132

Dimming: 32bit 0~100% linear dimming

Features: XY shaking head+beam+flash +XY infinity

Working temperature: -30~50℃

Stroboscopic frequency: 1~30HZ

Appearance: metal, black

Connection: DMX512 I/O/Power I/O.

IP grade: IP20

Input voltage: AC100-240V, 50/60HZ

LED: 6*OSRAM 40W RGBW LED

Driving current: 2.5A

Maximum power: 350W

Color temperature: 2800K-8500K

Lamp life: 80,000 hours

Beam angle: 3.5-35°

Control mode: DMX512, master-slave operation,

Channel mode: 18CH/32CH

Support RDM function, DMX software upgrade function

Vertical: 270°

Focus: High-quiet motor precision focus point, no jitter.

Display mode: color LCD display, Chinese and English display, reversible display.

Stroboscopic: 1-20Hz

Light: 0-100% (16 bits)

Operating environment temperature: 0-45℃.

Efficient heat dissipation system, full temperature monitoring, automatic overheating protection, no risk of lamp damage.

Intelligent speed regulating fan, real-time display of temperature

Features

·150W High Output White LED

·50,000 hours lifespan and low power consumption

·Zoom angle 4.5°~22 °, focus function

·High light output, 10500LUX@5M at White light zoom in, 990LUX@5M at White light zoom out

·Temperature protect function, when the internal Temperature is up to 40° then the fans begin to work, when the internal temperature is up to 70°and the brightness reduce half.

·1 Color Wheel: 7 colors+white, color fine tuning, rotation with variable direction and speed

·1 Rotation Gobo Wheel: 5 gobos + 2 open, wheel rotation and shake

·Prism: 8-facet Prism, bi-directional rotatable at variable speeds

·High speed strobe effect with 1-25 flashers per second

·Internal program available

·16/14 DMX Channels USITT DMX-512

·DMX 512, master-slave and sound activated controllable or auto operation

·Colorful LCD display

·Efficient low noise fan cooling system

·PowerCon IN/OUT

·3-pin & 5-pin XLR connectors IN/OUT

·Two 1/4 turn fastening Omega Clamps

·IP 20 protection rating

Specifications

Input Voltage: AC90-260V 50/60Hz

Light Source: 150W High Output White LED

Control Signal: DMX 512, master-slave and sound activated or auto operation

Control Channel: 16/14 DMX Channels USITT DMX-512

Power Consumption: 265W

Dimensions: 328(L)*220(W)*482(H)mm

Packing size: 365(L)*290(W)*600(H)mm

Net Weight: 12.35kg,    Gross Weight: 14.95kg

Features

·150W High Output White LED

·50,000 hours lifespan and low power consumption

·Beam Angle 6°, Outstanding sharp BEAM effect and remarkable wash effect with pure color mixing and focus Function

·High light output, 14020LUX@5M at White light

·Temperature protect function, when the internal temperature is up to 40° and then the fans begin to work, when the internal temperature is up to 70° and the brightness reduce half.

·Color Wheel: 7 colors +white, rotation with variable direction and speed

·1 static Gobo Wheel: 8 gobos +white, wheel rotation and shake

·1 Rotate Gobo Wheel: 6 gobos +white, wheel rotation and shake

·Prism: 8-facet Prism, bi-directionally rotatable at variable speeds

·High speed strobe effect with 1-25 flashers per second

·Internal program available

·16/14/12/10 DMX Channels USITT DMX-512

·DMX 512, master-slave and sound activated controllable or auto operation

·Specific computer control software as optional

·Colorful LCD display

·Efficient low noise fan cooling system

·POWERCON IN/OUT

·3-pin XLR connectors IN/OUT

·Two 1/4 turn fastening Omega Clamps

·IP 20 protection rating

Specifications

Input Voltage:  AC90-260V 50/60Hz

Light Source:  150W High Output White LED

Control Signal:  DMX 512, master-slave and sound activated or auto operation

Control Channel:  16/14/12/10 DMX Channels USITT DMX-512

Power Consumption:  250W

Dimensions:  270(D)*270(W)*470(H)mm

Packing Dimensions: 305(D)*305(W)*500(H)mm

Net Weight: 10.6kg,    Gross Weight: 12.6kg

Features

·200W High Output White LED

·50,000 hours lifespan and low power consumption

·Beam Angle 13°, focus function

·High light output, LUX8000@5M at White light

·Temperature protect function, when the internal Temperature is up to 40° then the fans begin to work, when the internal temperature is up to 70°and the brightness reduce half.

·Color Wheel: 7 colors +white, color fine tuning, rotation with variable direction and speed

·1 static Gobo Wheel: 8 gobos +white, wheel rotation and shake

·1 Rotation Gobo Wheel: 6 gobos +white, wheel rotation and shake

·Prism: 3-facet Prism, bi-directional rotatable at variable speeds

·High speed strobe effect with 1-25 flashers per second

·Internal program available

·19/17 DMX Channels USITT DMX-512

·DMX 512, master-slave and sound activated controllable or auto operation

·Colorful LCD display

·Efficient low noise fan cooling system

·PowerCon IN/OUT

·3-pin & 5-pin XLR connectors IN/OUT

·Two 1/4 turn fastening Omega Clamps

·IP 20 protection rating

Specifications

Input Voltage: AC90-260V 50/60Hz

Light Source: 200W High Output White LED with led round 24X0.5W RGB 3-in-1

Control Signal: DMX 512, master-slave and sound activated or auto operation

Control Channel: 19/17 DMX Channels USITT DMX-512

Power Consumption:320W

Dimensions: 328(L)*220(W)*482(H)mm

Packing size: 365(L)*290(W)*600(H)mm

Net Weight: 12.25kg,Gross Weight: 15.5kg

Power supply: AC100V-240V 50-60Hz

Maximum power: 600W

Light source: 37*15W four-in-one OSR lamp beads

Drive current: 2.5A

Color temperature: 2800K-8500K

Lamp life: 50000 hours

Spot angle: 4.5°-45°

Control mode: DMX512, voice control, self-propelled

Channel mode: 24CH/36CH/48CH

Support RDM function, circle control effect, Chinese and English display, can be reversed display, strobe: 1-20Hz Dimming: 0-100% (16bit) Working environment temperature: 0°C-45°C Efficient cooling system, full temperature Monitoring, over-temperature automatic adjustment protection, no risk of lamp damage, intelligent speed-adjusting fan

Features

·250W High Output White LED

·50,000 hours lifespan and low power consumption

·beam angle 3°, focus function

·High light output,28600LUX@5M at White light

·Temperature protect function, when the internal Temperature is up to 40° then the fans begin to work, when the internal temperature is up to 70°and the brightness reduce half.

·Color Wheel: 7 colors +white, color fine tuning, rotation with variable direction and speed

·1 Rotation Gobo Wheel: 7 gobos + white, wheel rotation and shake

·1 Static Gobo Wheel: 8 gobos + white, wheel rotation and shake

·Prism: 16-facet Prism & Honeycomb Prism, bi-directional rotatable at variable speeds

·Frost effect

·High speed strobe effect with 1-25 flashers per second

·Internal program available

·16/18 DMX Channels USITT DMX-512

·DMX 512, master-slave and sound activated controllable or auto operation

·Colorful LCD display

·Efficient low noise fan cooling system

·PowerCon IN/OUT

·3-pin & 5-pin XLR connectors IN/OUT

·Two 1/4 turn fastening Omega Clamps

·IP 20 protection rating

Specifications

Input Voltage: AC90-260V 50/60Hz

Light Source: 250W High Output White LED

Control Signal: DMX 512, master-slave and sound activated or auto operation

Control Channel: 16/18 DMX Channels USITT DMX-512

Power Consumption: 350W

Dimensions: 320(L)*220(W)*480(H)mm

Packing size: 365(L)*290(W)*615(H)mm

Net Weight: 13.50kg,Gross Weight: 16.50kg

Technical parameter:

Input voltage: AC100-240V 50-60HZ,

Rated power: 600W

Light source: 12*40W 4 in 1 OSR lamp beads

Control mode: DMX signal control, master-slave, voice control mode

Color temperature: 2800K-8500K

Lamp life: 50000 Hours

Scan 630 degrees horizontally and 200 degrees vertically. (16bit precision scan)

High-speed electronic adjustment strobe can reach 1-25 times per second or random strobe, the total dimming channel can control the light and shade change and closing of 4 main colors at the same time, uniform RGBW color mixing system and rainbow effect, can be adjusted by white LED Color temperature to get more colorful colors, beautiful blue and white LCD liquid crystal display

Built-in programs are available for selection, which can be run automatically or controlled by an external console

Strobe: 1-20Hz

Dimming: 0-100% (16bit)

Working environment temperature: 0°C-45°C efficient heat dissipation system, whole-process temperature monitoring, over-temperature automatic adjustment protection, no risk of lamp bead damage, intelligent speed regulation

Input voltage: AC100-240V, 50/60Hz

Light source: 200W LED white light beads

Power: 290W

DMX512 channel: 18CH

Display: 2.4 inch LCD display

Color wheel: 1 color wheel has 9 color pieces + white

Gobo: 2 gobos, 1 fixed gobo with 10 gobos + 1 white light, 1 rotating gobo with 7 gobos + white light

Prism: 1 rotating 4 prism

Dimming: 0-100% Linear Dimming

Strobe: 0-25/sec

Beam angle: 7-21°

Horizontal rotation angle: 540°, 8Bit/16Bit

Vertical rotation angle: 270°, 8Bit/16Bit

Temperature Control: Built-in temperature control overheating protection

IP protection class: IP20

Body size: 343*232*537mm

Net weight: 16kg

Gross weight: 19kg

Features

·250W High Output White LED

·50,000 hours lifespan and low power consumption

·Zoom angle 5.5°~30°, focus function

·High light output,13300LUX@5M at White light zoom in,

·950LUX@5M at White light zoom out

·Temperature protect function, when the internal Temperature is up to 40° then the fans begin to work, when the internal temperature is up to 70°and the brightness reduce half.

·Color Wheel: 7 colors +white, color fine tuning, rotation with variable direction and speed

·1 Rotation Gobo Wheel: 7 gobos + white, wheel rotation and shake

·1 Static Gobo Wheel: 8 gobos + white, wheel rotation and shake

·Prism: 8-facet Prism, bi-directional rotatable at variable speeds

·Frost effect

·High speed strobe effect with 1-25 flashers per second

·Internal program available

·16/18 DMX Channels USITT DMX-512

·DMX 512, master-slave and sound activated controllable or auto operation

·Colorful LCD display

·Efficient low noise fan cooling system

·PowerCon IN/OUT

·3-pin & 5-pin XLR connectors IN/OUT

·Two 1/4 turn fastening Omega Clamps

·IP 20 protection rating

Specifications

Input Voltage: AC90-260V 50/60Hz

Light Source: 250W High Output White LED

Control Signal: DMX 512, master-slave and sound activated or auto operation

Control Channel: 16/18 DMX Channels USITT DMX-512

Power Consumption: 350W

Dimensions: 320(L)*220(W)*480(H)mm

Packing size: 365(L)*280(W)*600(H)mm

Net Weight: 13.50kg,Gross Weight: 16.50kg

Technical parameter

power application

● Input voltage AC110V-240V, 50-250Hz

● Total power 500W

Bulb Specifications

● The main light source uses a single LED 300W white light with a color temperature of 8000K

● 16 Kerui RGBW 10W full-color LEDs are used around the head

● Lamp bead service life is 20,000 hours

Optical system

● Lighting angle 3°

● Linear dimming 0-100%

● Strobe 0-20s

color wheel

● 1 color disc: 7 color chips + white light

gobo

● 1 rotating gobo wheel: 7 replaceable gobos + 1 white light

● 1 fixed gobo wheel: 8 fixed gobos + 1 white light

Prism effect

● One 16 prism and one honeycomb prism, stackable, variable speed rotation

fog mirror effect

● Independent atomized lens, soft light

focusing

● Electronic focusing: ultra-smoothly adjust the focus, adjust the clarity of the pattern

scan system

● Driven by three-phase motor, fast, quiet, with automatic error correction reset

● Horizontal scan: 540°

● Vertical scan: 270°

cooling system

● Adopt powerful silent fan

● Temperature protection function: when the device temperature reaches 40°, the fan starts to rotate, and when the device reaches 70°, the power is halved

way to control

● International standard DMX512 signal control connection

● Control channel mode 25/18CH

● Product size: 330(L)*230(W)*560(H)mm,

● Product weight: net weight: 15.7kg, gross weight: 20kg

Power supply: AC90-240V, 50/60Hz

Its main board, lamp lighter and power supply added coating technology, with moisture-proof and dust-proof function, and it is used ball fan.

Total power: 600W

Light bulb: excellent light

Life: 1500 hours on average

Color temperature: 8500K

Bright current output: 19600LM, 400,000 brightness at a distance of 11 meters

Control mode: DMX512/self-propelled built-in program, voice control

Horizontal scan: 540° (160bit precision scan) electronic error correction.

Vertical scanning: 270° (160bit precision scanning) electronic error correction.

Prism disk: 8, 8+48

Color wheel: 14 colors + white light, adjustable half-step, rainbow effect

Beam angle: beam angle 5-50° atomization effect

Effect: double prism, beam, 14 fixed patterns, jitter, random motion and slow and fast switching effects in front and back directions, independent single-sided high-transparency atomization

Dimming: 0-100% linear dimming

Strobe: double-chip strobe (0.5-9 times/s)

Appearance: high temperature resistant alloy plastic

Net weight: 21KG

Gross weight: 24.5KG

Product size: 380*340*680M

Carton size: 48*42*74.5CM
