Input voltage: 100〜240Vac 50-60Hz

Maximum power: 580W

Light source: 12pcs 40W RGBW 4in1 led

Beam intensity: 1: 7

Zoom range: 5-35°

Inclination: more than 220 degrees

Life of LED: 50,000 hours on average

LED: pixel control

Strokes: 20 times a second.

Dimming: 0: 0% linear dimming

Channel: 20/57 two-channel mode

Control mode: DMX-512, self-propelled and sound

Cooling system: fan forced cooling system

Working environment: indoor

Net weight: 15 kg

Lamp size: 102 * 10.75 * 26.6 cm

Packing: 110 * 18 * 35.5cm

Gross weight: 17KG

SPECIFICATION

Rated voltage: AC95V-245V, 50/60Hz

Laser color: RGB 3in1

Laser source: RGB 3in1 500Mw *6PCS

Horse racing light source: 5050 three-in-one 0.3W*480PCS

Beam Light source: CREE LED5W*8PCS

Modulation signal: TTL modulation signal

Control mode: DMx512 signal control, self-running mode, voice control mode, master-slave mode

Control channel: 23/29/74 DMX512 channels

X-ray scanning: electrodeless scanning

Y-scan: 0-120°

Scanning system:stepper motor

Working environment: indoor

Lamp size: 85*9*32CM

Packing size: 92*27*35CM

Net weight: 15.5Kg

Gross weight: 17Kg

Voltage: 100V-240V 50HZ-60Hz

Its main board, lamp lighter and power supply added coating technology, with moisture-proof and dust-proof function, and it is used ball fan.

Total power: 600W, more convenient in equivalent power

Channel: 16 / 22ch

Control effect: DMX512, self-timing built-in program, voice control

Light bulb model: German compensation 17R light source, color temperature can reach 160,000 k

Pattern: double prism, double pattern, beam, pattern can be unlimited, double prism (16 prism, 16 + 8 knirles), double pattern (9 glass rotation patterns, 15 fixed patterns)

Color: 14 colors + white light, color adjustable half, rainbow effect frequency flash: 1-11 times / sec

Prism: 16 prism +8 prism double prism, superposed, rotatable function 0-100% mechanical dimming

Co-focus: electric focus, beam angle 0-4 atomization effect, using photoelectric reset system, after accidental misunderstanding

Can be automatically retrieved, 540 ° water level, interpretation of 8bit / 16bit, vertical 270 °

Interpretation 8bit / 16bit

Overheal protection IP protection level: IP20

Electronic ballast and AC / DC switching power supply.

Power factors are as high as 0.99, THD <20%, support light bulb power adjustment, light bulb power consumption is automatically reduced to support energy saving mode, in English, English can be convertible.

Weight: 20 kg

Power supply: AC100V-240V 50-60Hz

Maximum power: 1000W

Light source: 37*25W four-in-one OSR lamp beads

Drive current: 2.5A

Color temperature: 2800K-8500K

Lamp life: 50000 hours

Spot angle: 4.5°-45

°Control mode: DMX512, voice control, self-propelled

Channel mode: 24CH/36CH/48CH

Support RDM function, circle control effect, Chinese and English display, can be reversed display, strobe: 1-20Hz Dimming: 0-100% (16bit) Working environment temperature: 0°C-45°C Efficient cooling system, full temperature Monitoring, over-temperature automatic adjustment protection, no risk of lamp damage, intelligent speed-adjusting fan

Features: The latest third-generation motherboard, supports RDM, display programming. With built-in program.

Rated voltage: AC100V-240V, 50/60HZ

Light source: customized 350W 17R Osram (Japanese Phoenix wick) original Osram lighter

Total power: 600W

Beam angle: the parallel beam angle is 2.2-2.3°, and the solid image exit hole is 6mm

Linear dimming: independent dimming device, 0-100% linear dimming

High-speed  strobe: pulse  strobe, stroboscopic speed 1-20 times/s

Fixed color: 1 fixed color wheel, containing 13 color chips + white light, half-color effect, linear color conversion and two-way variable speed rotation rainbow effect

Static pattern: a fixed gobo wheel, containing 14 gobos + 1 flowing gobo

Prism: one (8+16) prism and one eight prism, the prisms can overlap

Focusing: using high-precision glass optical lens, electronic linear high-definition adjustment

Atomization: 1 independent atomization effect, soft and natural light spot

Color chip quality:special high-temperature resistant raw materials, to achieve strong and bright vividness.

Horizontal/Vertical: The horizontal scanning angle is 540°(16BIT precision scanning), the vertical scanning angle is 270° (16BIT precision scanning)

XY motor: three-phase motor. Three-phase motor drive, powerful, faster, more stable and quieter.

Lens size: 155mm

Channel mode: 18 international standard DMX512 channels

Light bulb function: channel switch bulb and turn on light bulb function

Appearance: High temperature resistant cast aluminum shell, adopting wind direction drainage and temperature intelligent monitoring technology

Net weight of lamp body: 24kg

Protection level: IP65

Lamp size: 40*33*65cm

Carton size: 51*44*67.5cm

The main technical parameters

Electrical parameters:

Input voltage: 100V~240V AC, 50/60Hz

Input Power: 450W @ 220V

Power factor: PF>0.9

Light source specifications:

Light source: 350W high brightness LED

Color temperature: 7500K-8000K

Rated life: 50000 hours

color:

1 color wheel: 7 colors + white light

Variable speed bidirectional rainbow effect

Step/Linear conversion color optional

Fixed gobo:

1 fixed gobo wheel: 8 gobos + white light

With variable speed jitter effect, two-way variable speed flow effect

To rotate the gobo wheel:

1 rotating gobo wheel: 7 gobos + white light

The pattern plate adopts a detachable design, which is more convenient to replace the pattern plate

Prism: 1 8 prism, can be rotated in both directions

Focusing: DMX linear focusing, super smooth focus adjustment.

Strobe/dimming: electronic strobe, 0.3-25 times/second / linear dimming

Atomization: independent atomization lens, softer light

Rotation angle:

Driven by three-phase stepping motor, fast, quiet, with automatic return function.

540° horizontally, 270° vertically

Beam angle: DMX linear amplification, beam angle 8-35 degrees free switch

Control mode: international standard DMX512 signal, 3-pin interface + 5-pin interface

18CH 16CH, 2 channel modes for selection

Other functions:

Horizontal and vertical speed adjustable

Adopt powerful silent fan, display LED temperature, reduce power due to overheating, and ensure LED service life

Modular structure for easy maintenance

Housing material/protection level:

High temperature/UV light resistant engineering plastic Protection grade: IP20

weight:

Net weight: 16kg Gross weight: 19kg

Outer packing size: (unit: mm)

390(L)*31(W)*710(H)

Working temperature:

Maximum ambient temperature 45°C

Power supply: AC110-240V, 50/60Hz

Its main board, lamp lighter and power supply added coating technology, with moisture-proof and dust-proof function, and it is used ball fan.

Light source: 380W

Total power: 600W, lighter and more convenient in the same power Dimming: 0-100% linear adjustment

Strobe: double-chip strobe (0.5-9 times/s)

Focus: linear focus

Zoom: linear zoom

Beam angle: 2°-60°

Atomization: 0-100% linear atomization

Colorful lens: 0-100% linear colorful lens

Optical lens: high-precision glued optical lens combination

Color: 1 fixed color wheel, 13 colors + white light, rainbow effect speed adjustable, half-step color effect

Fixed gobo: 1 fixed gobo wheel, 13 gobos + white light, bi-directional variable speed rotation

Effect wheel: 1 fixed effect gobo wheel, which can rotate at two-way speed

Rotating wheel: 1 rotating gobo disc, 7 replaceable gobo wheel + white light, the flow of patterns back and forth from slow to fast

Prism wheel: any two kinds of prism effects can be superimposed and combined prism dynamic effects, can be rotated forward and backward

Horizontal scan: 540° (160bit precision scan) electronic error correction.

Vertical scanning: 270° (160bit precision scanning) electronic error correction.

Channel mode: 24 international standard DMX512 channels, master-slave mode.

Display: color touch screen

Rectifier: The electronic rectifier makes the product lighter, brighter, the bulb is more stable, more environmentally friendly, and energy-saving.

Power supply: AC100V-240V 50-60Hz

Maximum power: 1000W

Light source: 19 * 40W four-in-one LED lamp beads

Lamp strip: 5050RGB 74PCS 0.12W colorful side luminous lamp strip

Color temperature: 2800K-8500K

Lamp life: 50,000 hours

Display: color screen

Strokes: 1 -25 times/second

Spot angle: 0-60

Dimming: 0-100% linear electronic dimming

Control mode: DMX512, voice control, self-propelled and master-slave

Channel mode: 24/26/38/81/95/100/102CH

Function: with CTO, dyeing, light beam,

Effect mode (whirlpool, kaleidoscope)

The front mirror plate can rotate in a variable direction and seamlessly splice the mirror plates,

Aspheric lens structure, single point control of lamp bead

Light effect: stroboscopic and horse racing effect, with built-in program.

Packing size: 580x550x375mm

Gross weight: 20kg

Features: The latest third-generation motherboard, supports RDM, display programming. With built-in program.

Rated voltage: AC100V-240V, 50/60HZ

Light source: original OSRAM 371 bulb

Total power: 700W

Beam angle: the parallel beam angle is 2.2-2.3°, and the solid image exit hole is 6mm

Linear dimming: independent dimming device, 0-100% linear dimming

High-speed strobe: pulse strobe, stroboscopic speed 1-20 times/s

Fixed color: 1 fixed color wheel, containing 13 color chips + white light, half-color effect, linear color conversion and two-way variable speed rotation rainbow effect

Static gobo: a fixed gobo wheel, containing 14 gobos + 1 flowing gobo

Prism: a sixteen prism and an eight prism, the prisms can overlap

Focusing: using high-precision glass optical lens, electronic linear high-definition adjustment

Atomization: 1 independent atomization effect, soft and natural light spot

Color chip quality:special high-temperature resistant raw materials, to achieve strong and bright vividness.

Horizontal/Vertical: The horizontal scanning angle is 540°(16BIT precision scanning), the vertical scanning angle is 270° (16BIT precision scanning)

XY motor: three-phase motor. Three-phase motor drive, powerful, faster, more stable and quieter

Lens size: 155mm

Channel mode: 18 international standard DMX512 channels

Light bulb function: channel switch bulb and turn on light bulb function

Appearance: High temperature resistant cast aluminum shell, adopted wind direction drainage and temperature intelligent monitoring technology

Net weight: 24kg

Protection level: IP65

Lamp size: 40*33*65cm

Carton size 51*44*67.5cm

Input voltage: AC100-240V 50-60Hz

Light source power: 700W

Its main board, lamp lighter and power supply added coating technology, with moisture-proof and dust-proof function, and it is used ball fan.

Focusing: linear electric focusing

Dimming: 0-100% mechanical dimming, smooth dimming without flicker

Light source: YODN MSD 440W

Ballast: YODN MSD R17/S20

Strobe: independent strobe, 0.5-20 times/s adjustable

Color wheel: a color wheel with 15 colors CMY infinite dyeing

Fixed gobo wheel: 15 fixed patterns + white

Rotating gobo wheel: 9 glass gobos + white

Prism 16 prism + 24 prism (standard, can be customized)

Control mode: DMX 512, voice control, self-propelled, master-slave

Rotation angle: X-axis 540°, Y-axis 270° can automatically correct positioning

Channels: Standard 16 channels, with CMY 20 channels

Light material: Used high-strength PA66, it has the characteristics of high temperature resistance, aging resistance, wear resistance, light weight and drop resistance.

Features: The latest third-generation motherboard, supports RDM, display programming. With built-in program.

Channel mode: 16 international standard DMX512 channels;

Light source: original OSRAM 461W;

Lamp life: 1600H

Voltage: 110-240v.50/60hz

Total power: 700w

Color: 14 colors + white light; with seven-color rainbow effect

Gobo: 17 gobos (including 6 glass gobos)

Prism wheel: a prism wheel (8+16+24+32)

Beam angle: 2.1°

Lens diameter: 189mm

Focusing: using high-precision glass optical lens, electronic linear high-definition adjustment

Atomization: 1 independent atomization effect, soft and natural light spot

Color chip quality: Imported from Italy, special high-temperature resistant raw materials, to achieve strong and bright vividness.

Horizontal/Vertical: The horizontal scanning angle is 540°(16BIT precision scanning), the vertical scanning angle is 270° (16BIT precision scanning)

XY motor: three-phase motor. Three-phase motor drive, powerful, faster, more stable and quieter.

Dimming: 0-100% mechanical dimming, mechanical gating and support

Use optical reset system

Positioning technology: The magnetic positioning system using magnetic devices replaces the traditional Hall positioning system, which has high accuracy, high performance and reliability.

Waterproof protection grade: IP65;

Weight: 31.6KG

Size: Length 428mm*Height 700mm*Width 287mm

Input voltage: AC90-240V 50-60Hz

Machine power: 600W

The theoretical life of the light source is more than 1500 hours

Bulb color temperature: 7800K

Focusing: linear electric focusing

Dimming: smooth dimming without flicker

Light source: OSRAM R17

Strobe: independent strobe, 0.5-20 times/s adjustable

Color/pattern/effect

Color wheel: 11 color chips

Beam angle: 2° to 60°

Fixed gobo wheel 12 bidirectional shaking, animation, and water effects

Replaceable gobo wheel: 9 glass gobos

Prism: 8 prism

Control mode: DMX 512, self-propelled, master-slave

Rotation angle: X-axis 540°, Y-axis 275° can automatically correct positioning

Channels: Standard 20 channels, streamlined channels 15 channels

Protection level: IP55

Product size: 418*378*620(mm) 25kg

Carton packaging: 72.5cm*46.5cm*50cm28kg

Flight case: 500*435*825mm 44kg 1pcs

925*500*825mm 82kg 2pcs
